Pro-Mod DK24 HH 2PT

Why we say this

Charvel list a Seymour Duncan Full Shred TB-10 in the bridge of the Pro-Mod DK24 HH 2PT (2962411500, 2962411303), in black, so this is the same pickup the guitar ships with. Duncan make Trembuckers with 52.6mm pole spacing to line up with tremolo string spacing, on slightly larger bobbins and baseplate than a standard humbucker, so a like-for-like Trembucker is the safe choice for this route. Four-conductor cable, which the DK24's five-way and series/parallel switching need.

Why we say this

Charvel list Charvel-branded die-cast locking tuners on the Pro-Mod DK24 HH 2PT but don't publish the hole size. Modern sealed and locking tuners like these normally sit in 10mm holes. Gotoh's SG381-07 MG-T locking set (SG381-07 MGT L6 CB) is sold for 10mm holes, and each tuner is fixed with one screw set at 45 degrees to the post, so if your tuners use guide pins or a screw in a different spot you may need to drill one small pilot hole per tuner. The stock tuners already lock, so this is a quality and feel upgrade rather than a new feature. Take one tuner off and check the hole and where the screw or pins sit before ordering.

Why we say this

Charvel list Charvel-branded die-cast locking tuners on the Pro-Mod DK24 HH 2PT but don't publish the hole size. Modern sealed and locking tuners like these normally sit in 10mm holes. Graph Tech make this set (PRL-9721-C0) for 13/32 inch (10mm) holes, with a two-pin casing and InvisoMatch plates included to use the screw holes left by common factory tuners. Graph Tech stagger the post heights so a flat headstock doesn't need a string tree. Take one tuner off and check the hole and where the screw or pins sit before ordering.

Why we say this

Charvel list Charvel-branded die-cast locking tuners on the Pro-Mod DK24 HH 2PT but don't publish the hole size. Modern sealed and locking tuners like these normally sit in 10mm holes. Hipshot make this set for 13/32 inch (10mm) holes and fix it with a screw, washer and nut, so if your tuners use guide pins you may need to drill one small pilot hole per tuner. The stock tuners already lock, so this is a quality and feel upgrade rather than a new feature. Take one tuner off and check the hole and where the screw or pins sit before ordering.
